PSU Recommendation

Crash Override

Hi,

My current PSU seems to be flaky or on it's way out in some degree (see my thread in Computers & Technology for more info [PSU Power Surge and BIOS access issue].

Just wondering if anyone has any reccomendations on a suitable PSU upgrade given the specs below:

System Info
Motherboard: ASUSZ87-Pro - BIOS Version 10.07 (05/17/13)
Power Supply: CoolerMaster V650 80+ Gold
Processor: Intel(R) Core(TM) i7-4770K CPU @ 3.50GHz (8 CPUs), ~3.5GHz
Memory: 8GB Cosair Vengence
GPU: NVIDIA GeForce GTX 1060 6GB
OS: Windows 10 Pro 64-bit (10.0, Build 18363)
Other: 1 SSD, 1 HDD, 1 Disc Drive.

I did look up a few a while back but everytime I found one that was a good price and seemed like a good unit, I always found someone to say that the coil noise was awful for the unit itself was unreliable. A 650 Watt I would think should be enough to run everything I have currently.

Thanks in advance.

SeanW

Firstly, it's a mistake to assume that more is necessarily better when it comes to rated wattage, as a good PSU can provide more power for your components safely than a bad PSU, even if the bad PSU has a higher rated wattage. At minimum, you need to check the more detailed sub-ratings on the PSU particularly to see how much amperage it can supply on the 12V rail (or rails), while the 3.3 and 5 volt rails are typically less of a concern. Sometimes companies will simply call a PSU "650W" when it really shouldn't be used for anything like that:

https://www.youtube.com/watch?v=MYo5-JIV4C0

You shouldn't need anything like 650W for that system. I put your specs (and a few assumptions) into an online PSU calculator and it came back with 367W recommending a Corsair 450W model.
https://outervision.com/power-supply-calculator

It's always a good idea to over-specifiy your PSU a little bit, just so that it's not working flat out, for that I'd recommend a good 500W PSU. I'm a fan of Seasonic, hard to go wrong with them, so you might consider something like this:
https://www.scan.co.uk/products/500w-seasonic-core-gold-gc-500-80plus-gold-single-rail-41a-120mm-fan-atx-psu
500W, pretty much all of that available on the 12V rail, or if you want to buy from within the EU:
https://www.komplett.ie/seasonic-core-gold-gc-500w/80054983/product/9426 (they used pictures from the 550W model).

Crash Override

Thanks for the reply and informative response!

As you can probably tell from the components this rig was built many years ago back when I knew a lot less about the intricacies of PC building.I definitely did hear before that too high a PSU can actually be a bad thing - I didn't realise mine was way over the recommended level.

I get a "ASUS Anti-Surge Was Triggered to protect system from unstable power supply unit" every once in a while (no graphics card and not playing games) and I get it very frequently when I amusing the GPU and playing games with it.

I just checked my current PSU and it can supply 54A to the 12V rail apparently.

Thank you for the suggestions too, I'll have a look into those!

SeanW wrote: »

Firstly, it's a mistake to assume that more is necessarily better when it comes to rated wattage, as a good PSU can provide more power for your components safely than a bad PSU, even if the bad PSU has a higher rated wattage. At minimum, you need to check the more detailed sub-ratings on the PSU particularly to see how much amperage it can supply on the 12V rail (or rails), while the 3.3 and 5 volt rails are typically less of a concern. Sometimes companies will simply call a PSU "650W" when it really shouldn't be used for anything like that:

You shouldn't need anything like 650W for that system. I put your specs (and a few assumptions) into an online PSU calculator and it came back with 367W recommending a Corsair 450W model.
https://outervision.com/power-supply-calculator

It's always a good idea to over-specifiy your PSU a little bit, just so that it's not working flat out, for that I'd recommend a good 500W PSU. I'm a fan of Seasonic, hard to go wrong with them, so you might consider something like this:
https://www.scan.co.uk/products/500w-seasonic-core-gold-gc-500-80plus-gold-single-rail-41a-120mm-fan-atx-psu
500W, pretty much all of that available on the 12V rail, or if you want to buy from within the EU:
https://www.komplett.ie/seasonic-core-gold-gc-500w/80054983/product/9426 (they used pictures from the 550W model).
